锯床主要特点
双立柱龙门卧式金属带锯床,主要用于锯切各种大型材料。具备高效率、高精度、省料节能等优点。
※ 双立柱龙门式结构,稳定性高,刚性强
※ 采用线型导轨升降,精度高
※ 双油缸控制,操作平稳
※ 切削速度液压控制,无级调速
※ 工件夹紧液压夹紧,操作方便
※ 电动自动送料
main features
double―column horizontal bandsawing machine mainly used
for all kinds oflarge―scalematerial sawing with high effciency highprecision
save material saving energyetc
※ double column structure vertical liftinghigh
stability
※ adopts linear guide rail and high precision
※ double oil cylinder control,to opertte smoothly
※ cutting
speed adopts hydraulic control,stepless speed regulation
※ the clamping of workpiece adopts
hydraulic clamping,
※ electric automatic feed
产品型号 | model no | gh42180 |
切削能力(mm) | cutting capacity | 1800 1800wx1800h |
带锯调线速(mm/min) | blade speed | 20-80(无级) |
带锯条规格(mm) | blade size | 80x1.6x16666 |
主电机功率(kw) | main motor power | 18.5 |
液压电机 | motor hydraulic | 7.5/2.2 |
冷却泵功率 | coolant pump | 0.25 |
工作夹紧方式 | workpicec clamping | 液压 |
锯条张紧方式 | blabe tensioning | 液压 |
外形尺寸(mm) | size outward | 74000×4800×5300 |
