冲压外圈滚针离合器和轴承组件
|
轴径 |
离合器型号 |
重量 |
外形尺寸 |
传动力矩 |
极限转速 | |||||
|
现行的 |
国外厂商 |
fw |
d |
c |
n |
na | ||||
|
mm |
ina |
托林顿 |
g |
mm |
nm |
rpm | ||||
| hfl 系列 | ||||||||||
|
8 |
hfl0822 |
hfl0822 |
fcbl-bk |
6.3 |
8 |
12 |
22 |
3.15 |
17000 |
12000 |
|
10 |
hfl1022 |
hfl1022 |
7.4 |
10 |
14 |
22 |
5.3 |
14000 |
11000 | |
|
12 |
hfl1226 |
hfl1226 |
fcb-12 |
18 |
12 |
18 |
26 |
12.2 |
11000 |
8000 |
|
14 |
hfl1426 |
hfl1426 |
20.3 |
14 |
20 |
26 |
17.3 |
9500 |
8000 | |
|
16 |
hfl1626 |
hfl1626 |
fc-16 |
22 |
16 |
22 |
26 |
20.5 |
8500 |
7500 |
|
18 |
hfl1826 |
hfl1826 |
24.4 |
18 |
24 |
26 |
24.1 |
7500 |
7500 | |
|
20 |
hfl2026 |
hfl2026 |
fcb-20 |
27 |
20 |
26 |
26 |
28.5 |
7000 |
6500 |
|
25 |
hfl2530 |
hfl2530 |
fcb-25 |
44 |
25 |
32 |
30 |
66 |
5500 |
5500 |
|
30 |
hfl3030 |
hfl3030 |
fcb-30 |
51 |
30 |
37 |
30 |
90 |
4500 |
4500 |
|
35 |
hfl3530 |
hfl3530 |
58 |
35 |
42 |
30 |
121 |
3900 |
3900 | |
