型号

外形尺寸

负荷

重量

d

d 1

d 2

d 3

i1

i2

s1

l

l1

l2

l3

d1

d2

d3

sz

α

kn

kg

sqz5-rs

5

m5x0.8

9

20

8

11

7

46

24

4

12

9

11

17

9

15

2.8

0.025

sqz6-rs

6

m6x1

10

20

11

12.2

8

55.2

28

5

15

10

13

20

11

15

3.7

0.041

sqz8-rs

8

m8x1.25

12

24

12

16

10

65

32

5

16

12.5

16

24

14

15

5.8

0.075

sqz10-rs

10

m10x1.25

14

30

15

19.5

11

74.5

35

6.5

18

15

19

28

17

15

8.4

0.12

sqz10-rs-1

10

m10x1.5

14

30

21

19.5

11

80.5

35

6.5

18

15

19

28

17

15

8.4

0.12

sqz12-rs

12

m12x1.25

17

32

17

21

15

84

40

6.5

20

17.5

22

32

19

15

11

0.18

sqz12-rs-1

12

m12x1.75

17

32

24

21

15

91

40

6.5

20

17.5

22

32

19

15

11

0.18

sqz14-rs

14

m14x1.5

19

38

22

23.5

17

103

45

8

25

20

25

36

22

11

15

0.27

sqz14-rs-1

14

m14x2

19

38

28

23.5

17

109

45

8

25

20

25

36

22

11

15

0.27

sqz16-rs

16

m16x1.5

22

44

23

25.5

19

112

50

8

27

22

27

40

22

11

15

0.36

sqz16-rs-1

16

m16x2

22

44

29

25.5

19

118

50

8

27

22

27

40

22

11

15

0.36

sqz18-rs

18

m18x1.5

23

45

25

31

20

130.5

58

10

32

25

31

45

27

11

19

0.54

sqz20-rs

20

m20x1.5

27

50

25

29

24

133

63

10

38

27.5

34

45

30

7.5

19

0.54

sqz22-rs

22

m22x1.5

27

52

26

33

24

145

70

12

43

30

37

50

32

7.5

23

0.76
