xxkg

c3/c5/c6/a5s/b10s/b10m

bm8d-xx-xxkg-6b

xxt

c3/c5/c6/a5s/b10s/b10m

bm8d-xx-xxt-6b

xxlb

a5s/b10s/b10m

bm8d-xx-xx-6yb

xxklb

a5s/b10s/b10m

bm8d-xx-xxk-6yb

100kg-300kg通过oiml c3级认证
3t-15t通过oiml c5级认证
500kg-2.5t通过oiml c6级认证
500kg-10t(1klb-20klb)s1型产品通过ntep a5s/b10s/b10m级认证

额定载荷

t

0.1/0.15/0.2/0.25/0.3/0.5/1/1.5/2/2.5/3/5/7.5/10

klb

1/1.5/2/2.5/2.5kle/3/4/5/5kse/7.5/10/15/20

精度

c3

c5

c6

b10s

a5m

b10m

最大检定分度数

n max

3000

5000

6000

iiil10000单只

iii5000多只

iiil10000多只

最小检定分度值

v min

emax/10000

emax/18000

emax/20000

emax/15000

emax/15000

emax/10000

综合误差

(%fs)

≤±0.020

≤±0.010

≤±0.009

≤±0.026

≤±0.026

≤±0.050

蠕变

(%fs/30min)

≤±0.016

≤±0.012

≤±0.008

≤±0.017

≤±0.017

≤±0.040

温度对输出灵敏度的影响

(%fs/10℃)

≤±0.011

≤±0.007

≤±0.006

≤±0.013

≤±0.013

≤±0.040

温度对零点输出的影响

(%fs/10℃)

≤±0.015

≤±0.014

≤±0.007

≤±0.014

≤±0.014

≤±0.020

输出灵敏度

(mv/v)

2.0±0.004

3.0±0.008

输入阻抗

(ω)

350±3.5

输出阻抗

(ω)

350±3.5

绝缘阻抗

(mω)

≥5000(50vdc)

零点输出

(%fs)

≤±1.0

温度补偿范围

(℃)

-10～+40

允许使用温度范围

(℃)

-35～+70

推荐激励电压

(v)

5～12(dc)

最大激励电压

(v)

18(dc)

安全过载范围

(%fs)

150

极限过载范围

(%fs)

300

atex等级（可选）

ii 1g ex ia ii 1c t4

ii 1d ex iad20 t73℃

ii 3g ex nl ii c t4

注：s1型输出灵敏度为2.0±0.004mv/v

尺寸

b

d

h

h

l

l1

l2

l3

l5

m

1k

30.7
(1.21)

13.5 (0.53)

30.2
(1.89)

24.76
(0.98)

130
(5.12)

15.7 (0.62)

25.4 (1)

101.6 (4)

57.1 (2.25)

1/2-20unf-2b

1.5k,2k

26
(1.02)

2.5k

31.3
(1.23)

13.5 (0.53)

31.3
(1.23)

27
(1.06)

3k～5kse

29.3
(1.15)

m12×1.75

0.5t

24.76
(0.98)

1t

26
(1.02)

1.5t～2t

29.3
(1.15)

2.5kle

36.8
(1.45)

19.8 (0.78)

36.8
(1.45)

32.8
(1.29)

171.5 (6.75)

19.1
(0.75)

38.1 (1.5)

133.3 (5.25)

76.2
(3.0)

3/4-16unf-2b

5k～15k

34.8
(1.37)

2.5t～5t

20.5 (0.81)

m20×2.5

20k

49.5
(1.95)

26.9 (1.06)

49.5
(1.95)

47.5
(1.87)

222.2 (8.75)

25.4
(1)

50.8 (2)

171.5 (6.75)

101.6 (4)

1-12unf-2b

7.5t～10t

m24×2
